BELL Smart LED Trailing/leading Edge Dimmer

Estimated delivery on this item from: £3.96

Final delivery charges are affected by quantities chosen and delivery service selected.
Estimated price above assumes "2nd class delivery" service selected.

Additional Information:
Bell Lighting LED Dimmer Module

Ideal for replacing existing backplate dimmer modules when retro-fitting LED lamps or fittings
Suitable for dimming: LED / CFL / Halogen / Incandescent

TECHNICAL SPECIFICATION
Name Smart LED Trailing/leading Edge Dimmer ­ Offset Spindle
Volts 240
Watts 5­100 - LED


Smart Universal LED Trailing/Leading Edge Dimmer Module
Smooth, flicker free, silent, buzz free dimming and easy set up
• Completely silent dimming
• Smooth flicker free dimming
• Wide dimming ranging from 100% to 10%
• Compatible with most lamps and fittings in the market
• 5W - 100W LED lamps (10 lamps maximum)
• 5W - 150W including Incandescent, Halogen & CFL lamps

10803 LED Dimmer Module
Ideal for replacing existing backplate dimmer modules when retro-fitting LED lamps or downlights
Suitable for dimming: LED / CFL / Halogen / Incandescent
Resistive Load
GLS - Min 5W ~ Max 150W
Mains voltage Halogen - Min 5W ~ Max 150W
Inductive Load
UNSUITABLE FOR dimmable magnetic transformer
Electronic transformer Min 10W ~ Max 150W
LED Load
LED Dimmable lamps - Min 5W ~ Max 100W - 10 lamps maximum
LED Dimmable lamps - Min 5W ~ Max 120W - 10 lamps maximum
Compact Fluorescent Load
CFL Dimmable lamps - Min 15W ~ Max 150W
