Optimum Digital Fused Spur Timer

Estimated delivery on this item from: £3.96

Final delivery charges are affected by quantities chosen and delivery service selected.
Estimated price above assumes "2nd class delivery" service selected.

Additional Information:
Optimum Digital Fused Spur Switched Timer

Digital fused-spur time switch
Suitable for patress box mounting
7 day programming logic control
Mains-linked switch, with a resistive rating of 13 Amps

The OP-DFST is a digital fused-spur time switch. The timer is suitable for patress box mounting. The 7 day programming logic controls a mains-linked switch, with a resistive rating of 13 amperes. There is an inbuilt rechargeable cell to keep the timer running in the event of a loss of mains power. The output can be disconnected by an integrated double-pole isolator switch; the load is protected by a replaceable BS1362 13 Ampere cartridge fuse, within a removeable caddy.

7 Day fused spur timer
Patress box mounting
Double-pole isolation
Supply Voltage: 220-240V AC 50Hz
Internally-linked mains switching
200 Hour running reserve
Dimensions: 85 x 85 x 30
Connections: 4 x wire-protect screw terminals
Weight: 150g
Power consumption: 1VA @ 230v 50hz
Resistive load: 13 Amperes
Inductive load: 2 Amperes (cos ø 0.6)
Minimum load: 100mA @ 240v ac
Runnning reserve: 200 Hours
Temperature rating: -20T55
Accuracy quartz regulated: (typically /- 2.5 sec / day)
Minimum switching period: 1 minute
Programme capacity: 24 on/off programmes
Manual override: fix on, timed, fix off & random
